One Piece 15 Degree Astra Tech Osseospeed Angled Abutments

Astra Tech Osseospeed® Titanium Angled Abutment

RP 3.5-4.0mm (Aqua)/ WP 4.5-5.0mm (Lilac) -- 15°/25° Degree

Desciption:

This angled abutment comes with a screw that takes a .050/1.27mm hex driver

This abutment is prep-able with a 1mm/2mm/3mm collar height. (Or according your customize request)

Angled abutments are available for cases where implants are not able to provide alignments leading to clinical parallelism.

15°/25° Angled Abutments in three cuff heights for pre-angulation.

Angled abutments are designed to be used with cemented prostheses.

They offer the clinician a wide range of three-dimensional options.

Material:
Ti 6AI-4V ELI (Supply from Germany)

Feature:

* Titanium interface abutment
* 1pc Screw Included

* Precision machined up to ± 5µm
* Combination of high fatigue strength
* Superior level of biocompatibility

* Can production Custom interface

Approved by CE, ISO 9001, ISO 13485

Points of Astra OsseoSpeed™ Straight Abutment:

TiDesign™ abutments are manufactured with a hex for indexing and are packaged as a kit with a final screw. TiDesign™ stock titanium abutments are available for all three (3.0 yellow, 3.5/4.0 aqua, 4.5/5.0 lilac) implant/abutment interface connection groups.

3.0 TiDesign™ abutments are machined with a emergence profile of 4.0mm and a choice of collar heights of 1mm, 2mm and 2.4mm. The 1mm and 2mm collar height abutments are straight and the 2.4mm collar height abutment has a 15 degree angle machined in relation to the flat side of the hex. Number markings indicate the emergence profile and a single black line indicates the 3.0 implant/abutment connection group.

Straight 3.5/4.0 TiDesign™ abutments are available with a choice of three emergence profiles (4.5, 5.5, 6.5mm) and a collar height of 1.5mm or 3mm for each emergence profile. Two angled abutments with a angulation of 20 degrees and a collar height of 3mm with a choice of two (4.5, 5.5mm) emergence profiles are also offered. Number markings indicate the emergence profile and a double black line indicates the 3.5/4.0 implant/abutment connection group.

4.5/5.0 connection diameter TiDesign™ abutments are machined with two (5.5, 6.5mm) emergence profiles and either a 1.5mm or 3mm collar. One 20 degree angled abutment with a emergence profile of 5.5mm and a collar height of 3.5mm is also available. Number markings indicate the emergence profile and the absence of a black line indicates the 4.5/5.0 implant/abutment connection group.

         ANGELS Dental Implant Solutions Center is one of the national high-technique enterprise and one of the professional milling center in China, which offers the dentists the best solutions of the highest quality and accuracy in implantology. We integrate R&D, manufacture and sales, and mainly engages in dental implant system, implant surgical tools and digital implant repair products.

        Our focus is on Being a reliable and reputable dental implant parts manufacturer and improving the lives of patients and dentists around the globe by providing complete top quality, innovative and affordable solutions that exceed standards of excellence in the rapidly growing field of dental implantology.

        Our products have passed the test and certification of the German TUV testing agency, and have the ISO13485 certificate. The raw materials used are all major brands in Germany and the United States, which can guarantee better quality, so you have no worries. We have more than 10 precision machining machines, which can respond quickly and meet your order requirements.
